RPI 2.5-PE Side Contact Push-in Ground Terminal Block
Technical Parameter
| Prod.Desp. | Din Rail Terminal Block-RPI Series Side Contact Push-in Spring Connection |
| Item No. | RPI2.5-PE |
| Material | PA/Brass |
| Thickness(mm) | 5.2 |
| Width(mm) | 53.6 |
| Depth(mm) | 40/42.5/47.5 |
| Connection | Spring Push-in |
| Cross Section(mm2) | 0.14--4.0(Solid Wire)/0.14-2.5(Flexible Wire) AWG26-12 |
| Rated Voltage(V) | - |
| Rated Current(A) | - |
| Strip Length(mm) | 10 |
| Flammability | V0 |
| Standard | IEC60947-7-1;GB/T14048.7 |
| DIN Rail | U |
| Color | Yellow-Green |
| End Plate | D-RPI2.5/4 |
| Marking Strip | ZB5/ZB5 Orange |
| Jumper | FBS2-5/3-5/4-5/5-5/10-5 |
| Certificate | CE/RoHS/REACH |
| Standard | IEC60947-7-2 GB/T14048.8 |
